40-Series Integrated Tapered Headset for IS42 and IS52 Standards

Description

Super-smooth steering, quality materials, cutting-edge design, and serious durability are all hallmarks of Cane Creek’s 40-Series headsets.

Specifications

• Technical Description: IS42/28.6/H9/K|IS52/40/H1
• Top Type: IS – Integrated
• Top Head Tube Inside Dia.: 42.00mm
• Stem Clamp Dia.: 28.6mm
• Top Stack Height: 9mm (Short), 15mm (Tall)
• Top Bearing Type: Black Oxide, Sealed
• Bottom Type: IS – Integrated
• Bottom Head Tube Inside Dia.: 52.1mm
• Crown Race Seat Dia.: 39.79mm
• Crown Race Type: Steel, Face-Sealed
• Bottom Stack Height: 1mm
• Bottom Bearing Type: Black Oxide, Sealed
• Material: 6061 aluminum
• Weight: 84g
